BPB Press Fit Bronze Bush

CloseNextPrevious



CloseNextPrevious

BPB: Press Fit Bush



CAD Viewer Technical Data

Choose your Part

Please select desired options to reveal part number, price and availability

CAD Viewer Technical Data

Product Description

BPB Press Fit Bush, Bronze lined

These self lubricating press fit or slide fit bronze lined bushes are a precision guiding element used for press and mould tools. High quality case hardened steel, for a long, trouble free service life. Compatible wth PP guide pillars.

The primary reason to use alternative materials for sliding tools is to achieve a good compromise between the friction coefficient, wear of materials and cost of the product. Bronze is often the best solution, because of the average coefficient of dynamic friction, called μrd. If compared to Steel/Steel sliding (0.3), it is about half on dry Steel/Bronze surfaces (0.18), but if used with lubricating grease, the coefficient of the Bronze becomes extremely low (0.04) contrary to the Steel (0.12).

Specification

Case hardened steel with an internal bronze lined bush, and oil groove for additional lubrication.

Hardness - HRc 60-62
